行同步信号：a时=0其他时候为1

帧同步信号：o时=0其他时候为1

数据有效：只有处于，c与q时数据有效



verilog:计数的时序图：行计数为0---799共800个像素点其中只有640个有效像素点，其余为消隐



erilog：参考程序（DE2-115）

module VGA_Ctrl ( // Host Side

iRed,

iGreen,

iBlue,

oCurrent_X,

oCurrent_Y,

oAddress,

oRequest,

// VGA Side

oVGA_R,

oVGA_G,

oVGA_B,

oVGA_HS,

oVGA_VS,

oVGA_SYNC,

oVGA_BLANK,

oVGA_CLOCK,

// Control Signal

iCLK,

iRST_N );

// Host Side

input [9:0] iRed;

input [9:0] iGreen;

input [9:0] iBlue;

output [21:0] oAddress;

output [10:0] oCurrent_X;

output [10:0] oCurrent_Y;

output oRequest;

// VGA Side

output [9:0] oVGA_R;

output [9:0] oVGA_G;

output [9:0] oVGA_B;

output reg oVGA_HS;

output reg oVGA_VS;

output oVGA_SYNC;

output oVGA_BLANK;

output oVGA_CLOCK;

// Control Signal

input iCLK;

input iRST_N;

// Internal Registers

reg [10:0] H_Cont;xv

reg [10:0] V_Cont;

// Horizontal Parameter

parameter H_FRONT = 16;

parameter H_SYNC = 96;

parameter H_BACK = 48;

parameter H_ACT = 640;

parameter H_BLANK = H_FRONT+H_SYNC+H_BACK;

parameter H_TOTAL = H_FRONT+H_SYNC+H_BACK+H_ACT;

// Vertical Parameter

parameter V_FRONT = 11;

parameter V_SYNC = 2;

parameter V_BACK = 31;

parameter V_ACT = 480;

parameter V_BLANK = V_FRONT+V_SYNC+V_BACK;

parameter V_TOTAL = V_FRONT+V_SYNC+V_BACK+V_ACT;

assign oVGA_SYNC = 1'b1; // This pin is unused.

assign oVGA_BLANK = ~((H_Cont<H_BLANK)||(V_Cont<V_BLANK));

assign oVGA_CLOCK = ~iCLK;

assign oVGA_R = iRed;

assign oVGA_G = iGreen;

assign oVGA_B = iBlue;

assign oAddress = oCurrent_Y*H_ACT+oCurrent_X;

assign oRequest = ((H_Cont>=H_BLANK && H_Cont<H_TOTAL) &&

(V_Cont>=V_BLANK && V_Cont<V_TOTAL));

assign oCurrent_X = (H_Cont>=H_BLANK) ? H_Cont-H_BLANK : 11'h0 ;

assign oCurrent_Y = (V_Cont>=V_BLANK) ? V_Cont-V_BLANK : 11'h0 ;

// Horizontal Generator: Refer to the pixel clock

always@(posedge iCLK or negedge iRST_N)

begin

if(!iRST_N)

begin

H_Cont <= 0;

oVGA_HS <= 1;

end

else

begin

if(H_Cont<H_TOTAL)

H_Cont <= H_Cont+1'b1;

else

H_Cont <= 0;

// Horizontal Sync

if(H_Cont==H_FRONT-1) // Front porch end

oVGA_HS <= 1'b0;

if(H_Cont==H_FRONT+H_SYNC-1) // Sync pulse end

oVGA_HS <= 1'b1;

end

end

//|--------|

//____|-------------

// Vertical Generator: Refer to the horizontal sync

always@(posedge oVGA_HS or negedge iRST_N)

begin

if(!iRST_N)

begin

V_Cont <= 0;

oVGA_VS <= 1;

end

else

begin

if(V_Cont<V_TOTAL)

V_Cont <= V_Cont+1'b1;

else

V_Cont <= 0;

// Vertical Sync

if(V_Cont==V_FRONT-1) // Front porch end

oVGA_VS <= 1'b0;

if(V_Cont==V_FRONT+V_SYNC-1) // Sync pulse end

oVGA_VS <= 1'b1;

end

end

endmodule
